SPS 2019: Changing industrial networks

Solutions, ideas and technologies for plant operators and designers

SPS 2019 (Nuremberg)

Automation networks: Smart networking in every dimension -
What can plant operators/installers expect in the next few years?

Increasing plant networking, increasingly complex plant processes and growing competitive pressure: the next evolutionary stage of Ethernet-based machine and plant networks awaits you! Are you ready?

PROFINET V2.4, artificial intelligence, TSN and many other innovations are currently occupying the experts for industrial automation. Even if all these innovations are the logical next step in the evolution of proven automation technologies, many questions arise for plant operators and installers. Among others:

  • What is behind the current innovations? Which ones are relevant for whom?
  • What effects do TSN, Gigabit & Co. have on existing network solutions (including PROFINET)?
  • What opportunities and advantages can plant operators already benefit from?

As a long-standing expert for high-performance industrial networks, we support you in this,

  • to understand innovations,
  • to discover potentials and
  • Recognizing the need for action in good time.

SPS 2019 – Experience Indu-Sol.

  • Network planning and conception
    Vulnerability plant network? Availability can be planned.
  • Network diagnostics
    Predictive maintenance instead of repair - that's how it works.
  • Network infrastructure
    Onboard diagnostics, NAT routing, Gigabit - Increase your network performance!

PROFINET V2.4: The next step for the increased requirements of today and tomorrow (examples)



PROFINET V2.3 (till 2019)

PROFINET V2.4 (from 2020)

Network speedmax. 100 Mbit/s> 1 Gbit/s (1,000 MBit/s)
Prioritization options for data trafficPROFINET data before non-PROFINET data trafficCustomizable configuration through data traffic control via TSN
Scope of functions (according to conformity classes)Conformance Class A to CConformance Class A to D
Real-time communicationCycle times up to 31.25 μs
(PROFINET IRT)
Cycle times at 10 μs
(plus isochronous, cyclic communication)

Would you like to learn more about the upcoming challenges of machine and plant networks?

Our experts will advise you on practical and innovative solutions for increasing the efficiency and performance of your industrial networks.

Which features will significantly influence our industrial networks in the coming years?

Brief overview of Gigabit Ethernet in industrial automation

Gigabit Ethernet: For more resilient plant networks

The increasing data volume in industrial networks is increasingly pushing the existing infrastructure to its limits. Operators often underestimate the importance of required bandwidth reserves with which network and system failures can be prevented.

With PROFINET V2.4, data transmission in the gigabit range can be increased. However, a gigabit-capable network infrastructure is a prerequisite. Industrial switches in particular must be able to cope with the new flood of data.

Brief overview of TSN in industrial automation

PROFINET@TSN: The new standard for real-time data

Time-Sensitive Networking (TSN) forms the basis for delay-free data communication. In addition to the known prioritization of data streams, "fixed data routes" (streams) can be defined or time-uncritical data packets can be split up (pre-emption).

As intelligent data crossovers, industrial switches play a decisive role in real-time critical data communication. Thanks to TSN, plant operators benefit from a previously unheard of cross-manufacturer compatibility.

Brief overview of Conformance Class D (CC-D)

Conformance Class D - for the fusion of PROFINET and TSN

Anyone who wants to take advantage of all the benefits of the new PROFINET specification V2.4 will in future need PROFINET IO devices that support the new Conformance Class D (CC-D). This device classification primarily covers the complex functionalities of TSN.

The new CC-D is based on the previous conformance classes CC-B and CC-C. However, the new Conformance Class D integrates data communication via TSN. The new Conformance Class is therefore a special case.

Indu-Sol: Your partner for industrial networks. Strong know-how for your success.

SPS 2019: Industrial Automation - Industrial Ethernet Planning and Consulting

Network planning and conception

With a future-proof network structure, create the conditions for keeping the increasing networking of machines and systems under control!

With clearly defined responsibilities, demand-oriented infrastructure components and targeted network management, you can lay the foundation today for a secure tomorrow.

SPS 2019 Nuremberg: Industrial Automation - Network components for Industrial Ethernet, PROFINET & Co.

Network infrastructure

The choice of infrastructure components has a significant influence on the performance of your fieldbus or network.

No matter if growing data volume, higher EMC load or increased safety requirements - at Indu-Sol you will find the right components for a stable and safe data communication.

SPS 2019 Nuremberg: Industrial Ethernet network diagnosis and monitoring

Network diagnostics

Decentrally determined status data form the basis for central monitoring of the overall network status, targeted network management and predictive maintenance.

Benefit from modern and predictive maintenance through the AI-based status analysis of your plant network.
