Modular and compact industrial switches (manageable)

The industrial switches are installed in casings and have a variable number of Cu / LWL ports. The devices meet the elevated requirements of industrial uses e.g. EMC / temperature / 24 VDC. All devices are fully manageable and can thus be used for ISI (commissioning / service / maintenance).

• Selection parameters for manageable switches

Ethernet/PROFINET Switch PROmesh P9

The Indu-Sol Ethernet/PROFINET Switch PROmesh P9 is equipped for the increased performance requirements in the industrial ethernet and conforms to Conformance Class B requirements. This functionality makes it possible to integrate the switch into the automation system (Step7, TIA Portal) by an engineering tool in order to make a comprehensive network diagnostics feasible.

Highlights:
✓ Leakage current monitoring ✓ 9 x 100 MBit/s RJ45 ports ✓ Optimised shielding contact ✓ Compact design ✓ Displays port utilisation and discards on web interface

• Technical details

PROFINET/Ethernet Switch PROmesh P20

The PROFINET/Ethernet Switch PROmesh P20 is another switch of the PROmesh series from Indu-Sol. The functions of the Promesh P9 can be found in this switch. In addition to the 20 ports, the switch has firewall functionality and gigabit support.

Highlights:
✓ Leakage current monitoring ✓ 16 x 10/100 MBit/s RJ45 ports ✓ 4 x 1000Base-X SFP ports ✓ Optimised shielding contact ✓ Compact design ✓ Displays port utilisation and discards on web interface ✓ NAT Routing/Firewall function ✓

• Technical details

Ethernet Switch PROmesh P28-R

The Ethernet Switch PROmesh P28-R is designed for machine and system-level communication and for 19-inch rack mounting. This switch is available with and without routing functionality.

P = Ports
R = Rack
L = Layer

Ethernet Switches of the PROmesh Series for DIN-rail mounting

The PROmesh family from Indu-Sol also offers the following Ethernet switches.

P = Ports
E = Ethernet
GE = Gigabit Ethernet
PoE = Power over Ethernet

Ethernet/PROFINET Switch PROmesh FX

The managed switches of the PROmesh FX series have, in addition to the 6x RJ45 ports, two fiber optic ports for a network extension of up to 30 km. The system can be used for line structures as well as for redundant ring structures.

In addition to the complete PROFINET functionality and the integrated diagnostics of the fiber optic, many useful management functions can be used.

Fiber type:
SM = Single Mode
MM = Multimode

Fiber-connector:
SC = SC-Connector
ST = ST-Connector

• Technical details

Round plug connector IE Fast Connect Plug PRO M12 (D coded)

The customizable M12 connectors permit an easy on-site assembly by its insulation displacement connection.

• Technical details

Connector RJ45 Plug Fast Connect 180°/90°

With the Connector RJ45 plugs an Industrial Ethernet fast-connect line can be optimally connected to terminal devices and network components.

• Technical details

Connector RJ45 Plug configurable

The RJ45/8A Cat 6A plug can be used for transmission rates of up to 10 Gbps. The connector is equipped with insulation-displacement contacts, which means that no special tools are required for configuration. It can be used with PROFINET, Standard Ethernet and Ethernet Installation cables. The connector is fully shielded and suitable for industrial application in harsh conditions.

• Technical details

Control cabinet bushing SSD
