PROFINET DiagnosticDUO Online

Teamwork of Topology and Diagnosis

PROFINET DiagnosticDUO

Unique in the market!
For the first time, the status of the communication quality of every single device is displayed in a topology map. Diagnosis at a glance...with our PROFINET DiagnosticDUO.

The package acts like a navigation system for your PROFINET installation and leads you targeted and quickly to all failure points of your system – for a reliable operation and a quick reaction in case of abnormalities. Due to the teamwork of the live topology and the diagnosis display the position of every PROFINET node is visible immediately and in addition the health status is displayed by traffic light colours.

Teamwork of diagnosis and topology

Teamwork of diagnosis and topology

The software PROscan® Active V2 works hand in hand with the PROFINET-INspektor® NT. The topology software provides a current 360 degree view of your system at any time including comprehensive information on nodes and connections like IP /MAC address, line depth, cable lengths, damping reserves etc. Additionally traffic light colours at every node display the health status. Basis for it is the logical telegram traffic, which is analysed and monitored permanently of the PROFINET-INspektor® NT. In case of abnormalities of the network load, data transmission speed, data throughput or telegram jitters, telegram repetitions, error telegrams, diagnoses and device failures the display turns into yellow or red status.

Don't miss our special offer, because a permanent use ensures the reliable operation of your system.

The PROFINET DiagnosticDUO includes:

PROscan<sup>®</sup> Active V2

PROscan® Active V2

Detect the network topology quickly and clearly

Product details
PROFINET-INspektor<sup>®</sup> NT

PROFINET-INspektor® NT

Intelligent measuring point for online analysis

Product details

Product Details

Request offer for PROFINET DiagnosticDUO
Product name Art. No.
124030020


Further information

PROFINET Guidelines

This product meets important requirements of the PROFINET Design Guideline and Commissioning Guideline of PROFIBUS & PROFINET International. Read more about further criteria and products!


PROFINET brochure

PROFINET brochure Indu-Sol GmbH

Technological coherences in detail that are based on the latest valid standards and guidelines

Catalogue

Catalogue 2013/2014 Indu-Sol GmbH

Solutions and products for fieldbus and network analysis
